Motor
Motor
Bafang 500w 120Nm G340 (BBS02)
Top Speed
32km/h (default) / 48km/h (unlocked)
Configuration Class
1, 2, 3 (configurable)
Throttle
100% Power on Demand
Pedal Assist Level
5 Levels
Battery
Primary Battery
48v 15Ah Samsung 21700 50E Cell (720Wh)
Secondary Battery (Optional)
48v 15Ah Samsung 21700 50E Cell (720Wh)
Range*
Primary (Up to 70km) / Primary + Secondary (Up to 140km)
Charge Cycle
800
Charge Time
5 Hours
Frameset
Frame
6061 Aluminum Alloy
Fork
SR Suntour with Lockout
Wheels
Tire
Kenda with K-Shield Puncture Resistance
Tire Size
27.5" x 2.10"
Rim
Double Wall
Drivetrain
Shifter
Shimano Rapid Fire 7-Speed
Rear Derailleur
Shimano Acera
Crank
44T Single Guard
Freewheel
Nickel Plated 11-32T 7-Speed
Pedal
Wellgo Aluminum Platform
Components
Saddle
Selle Royal LOOKIN Basic (GEL)
Brake
Dual Piston Hydraulic Disc 180mm
Brake Lever
Safety Motor Inhibitors
Stem
Adjustable Stem High Rise
Seat Post
350mm x 31.6mm
Pedal Assist Sensor
Speed & Cadence Sensor
Weight
Weight
65lbs (Including Battery)
Load Capacity
275lbs
* Range may vary and fluctuate depending on several factors - most notably the weight of the user, steepness, terrain, extent of power assist, and throttle use.
Please note some parts may be replaced with those different from what is listed. Rest assured, all parts are thoroughly tested to guarantee compatibility and performance.
